Crushing Machine
Description
Toothed plate, hammer, sieve mesh and other quick-wear parts are manufactured with thickened alloy steel materials. Of strong wear resistance, you will not be bothered by the regular replacement of spare parts. When crushing the raw materials, maybe you are worried about the influenced quality for the mixed metals. Then, this equipment is equipped with a strong magnet to remove the iron. Thus the metal impurities in the raw materials are thoroughly removed to ensure that the crushed materials have high quality.
If you are choosing this crushing machine, our discharge system can be cooperated to achieve the best crushing effect.
Application
This equipment is used to process pine, wood, poplar, bamboo and palm fruit, as well as grinding various fiber materials such as straw. It is widely applied in feed mill, wood-working factory, crop processing factory and other industries.
| Model | BX-CF800 | BX-CF1000 | BX-CF1300 |
| Power (KW) | 45/55kw | 90KW | 132KW |
| Speed (r/min) | 1500-1700 | 1500-1600 | 1400-1500 |
| Feeding speed (kg/min) | 10-50 | 10-50 | 10-50 |
| Hammer number (pcs) | 48 | 72-80 | 96-104 |
| Output (T/H) | 3-10m3（1-3tph） | 5-20m3（2-4tph） | 8-30m3（3-6tph） |
| Machine weight (kg) | 800 | 2600 | 3300 |
| Machine size 9L*W*H) | 2200*1400*1500mm | 2500*1600*1600mm | 3000*700*1700mm |
- This crushing equipment adopts thick materials to prevent the equipment from being damaged when crushing heavy materials.
- Having three functions of coarse crushing, fin crushing and centrifugal grinding, users can select based on their own demands.
