Steel Silo
Description
Our steel silo is mainly made up of steel plate. It can be used to store feed, grain and oil, food, coal, brewing, building materials and other pellet and powdery materials. Thus it is widely applied in industry and agriculture, urban and rural, environmental protection and other fields.
| Specification (ton/silo) | Silo diameter (m) | Silo height (m) | Silo layers | Volume (m³) |
| 30 | 3.6 | 3.36 | 3 | 48.6 |
| 50 | 4.5 | 5.6 | 5 | 111 |
| 100 | 4.5 | 7.84 | 7 | 148 |
| 300 | 7.3 | 9.02 | 8 | 455 |
| 7.3 | 10.14 | 9 | 452 | |
| 500 | 8.2 | 12.38 | 11 | 768 |
| 8.2 | 13.5 | 12 | 756 | |
| 800 | 10 | 12.38 | 11 | 1181 |
| 10 | 13.5 | 12 | 1140 | |
| 1000 | 11 | 12.38 | 11 | 1430 |
| 11 | 14.62 | 13 | 1469 |
- The height of this steel silo can reach up to over 50m, having large volume, small foot print and low standard base.
- This silo features full mechanical operation, high construction technology and safe using.
- Our silos have short construction period, saving labor coat and construction cost for customers.
- The stored materials have high automatic discharge rate of more than 90%. It is not easy for the materials to be piled up, thus requiring no silo cleaning for clients.
Founded in 1996, LoChamp is dedicated to the production of mechanical equipment sets used for animal feed, organic fertilizer, and biomass fuel. We can provide customers with comprehensive solutions including design, production, installation, and maintenance as well as complete animal feed projects, biomass projects, fertilizer projects and silo projects.
